DL102-40W
Exlite
This track spot is featured with integrated design, powerful light output (up to 3000 lumens), interchangeable reflector system of high efficiency (up to 93%) and perfect glare control optics (UGR<13). Plus honeycomb and barn door accessories, all these make the product a perfect versatile lighting tool that can be used for retail shops, showrooms, public buildings and museums. Moreover, the highly efficient reflector with 12,20 and 45 degrees beam angle in combination with the latest COB LED technology makes the product stand out from its counterparts and an ideal choice for both accent and general lighting applications. This track mounted luminaire is also available in pendant and surface mounted forms.
Light source: | COB |
Input Voltage: | AC220~240V 50/60Hz |
LED Current: | 500mA (35-37V) |
Rated life: | >50,000 hours |
Operating temperature: | -20℃~40℃ |
Storage temperature: | -30℃~60℃ |
Certificate: | TUV/CE/RoHS |
Dimmability: | Dimmable Optional |
Weight: | 0.5KG |
Master carton dimensions(mm): |
L140*W140*H160mm (Box) L730*W310*H350mm(Outer carton ) |
Quantity per carton(PCS): |
1pc/box 20pcs/CTN |
G.W. Carton (Kg): |
0.7kg/box 15kg/carton |
Power | CRI | Beam Angle | Luminous | CCT | Housing | Part Number |
20W | >80 | 15° | 2190 lm | 3000K | DL081-20W-830-W-15-02 | |
2190 lm | 4000K | DL081-20W-840-W-15-02 | ||||
28° | 2190 lm | 3000K | DL081-20W-830-W-28-02 | |||
2180 lm | 4000K | DL081-20W-840-W-28-02 | ||||
36° | 2190 lm | 3000K | DL081-20W-830-W-36-02 | |||
2180 lm | 4000K | DL081-20W-840-W-36-02 | ||||
>90 | 15° | 1810 lm | 3000K | DL081-20W-930-W-15-02 | ||
2000 lm | 4000K | DL081-20W-940-W-15-02 | ||||
28° | 1800 lm | 3000K | DL081-20W-930-W-28-02 | |||
1990 lm | 4000K | DL081-20W-940-W-28-02 | ||||
36° | 1800 lm | 3000K | DL081-20W-930-W-36-02 | |||
2000 lm | 4000K | DL081-20W-940-W-36-02 |
